| Print |
|
| Printing Method |
Colour Laser Beam Printing |
Print Speed
(A4: mono / colour) |
38 / 38ppm |
| Print Resolution |
600 × 600 dpi
9600 (Equivalent) × 600 dpi |
First Print Out Time (FPOT)
A4 (mono / colour) |
5.1 / 6.0secs. |
| Print Language |
UFR II, PCL6, PostScript 3, PDF, XPS |
| Warm-up Time (from power on) |
31secs. or less |
| Recovery Time (from sleep mode) |
Approx. 6secs. |
| Auto Duplex Printing |
Standard |
Available Paper Size for Auto Duplex Print
(Paper Weight: 60 - 163g/m2) |
A4, B5, A5, Legal *1 , Letter, Executive, Foolscap, Indian Legal |
| Paper Handling |
|
Paper Input
(Based on 80g/m2） |
Standard Cassette |
550 sheets |
| Multi-Purpose Tray |
100 sheets |
| Optional Paper Feeder |
550 sheets (x3) |
| Maximum Paper Capacity |
2300 sheets |
Paper Output
(Based on 64g /m2） |
200 sheets (face down) |
| Paper size |
Standard Cassette |
A4, B5, A5, A6, Letter, Statement, Executive
Custom sizes (Width: 101.6.0 - 215.9mm
Length: 148.0 - 297.0mm) |
| Multi-Purpose Tray |
A4, B5, A5, A6, Legal *1, Letter, Statement, Executive, Foolscap, Index Card, Indian Legal
Envelope: COM10, Monarch, C5, DL
Custom sizes (Width:76.2 - 215.9 mm Length: 127.0 - 355.6 mm) |
| Optional Paper Feeder |
A4, B5, A5, A6, Legal *1, Letter, Statement, Executive, Foolscap, Indian Legal
Custom sizes (Width:101.6.0 - 215.9mm
Length: 148.0 - 355.6 mm) |
| Paper Weight |
Standard Cassette |
60 - 163g/m2
|
| Multi-Purpose Tray |
60 - 216g/m2
|
| Optional Paper Feeder |
60 - 163g/m2
|
| Paper type |
Plain, Recycled, Color, Heavy, Label, Postcard, Envelope |
| Connectivity & Software |
|
| Standard Interfaces |
Wired |
USB2.0 High Speed, USB Host (x3), 10 Base-T / 100 Base-TX / 1000Base-T |
| Expansion Slot |
SD Card |
| Network Protocol |
Print |
LPD, RAW, IPP / IPPS, WSD-Print (IPv4, IPv6) |
| TCP / IP Application Services: |
Bonjour (mDNS), HTTP, HTTPS, DHCP, BOOTP, RARP, ARP + PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
| Management |
SNMPv1, SNMPv3 (IPv4, IPv6) |
| Network Security |
Wired: |
IP / Mac address filtering, IEEE802.1x, SNMPv3, HTTPS, IPSEC |
| Department ID Management |
Yes, Up to 300 IDs |
| Mobile Print |
Canon PRINT Business, Apple® AirPrint™, Mopria® Print Service, Google Cloud Print ™, Canon Print Service |
| Other Features |
Secure Print, Memory Media Print |
| Compatible Operating Systems *2
|
Windows 10 (32-bit / 64-bit),
Windows 8.1 (32-bit / 64-bit),
Windows 8 (32-bit / 64-bit),
Windows 7 (32-bit / 64-bit),
Windows Vista (32-bit / 64-bit)
Windows Server 2012 R2 (64-bit),
Windows Server 2012 (64-bit),
Windows Server 2008 R2 (64-bit),
Windows Server 2008 (32-bit / 64-bit),
Windows Server 2003 R2 (32-bit / 64-bit),
Windows Server 2003 (32-bit / 64-bit),
Mac OS X 10.6.8 & up, Linux |
| General Specification |
|
| Device Memory |
1GB |
| Operation Panel |
5-line LCD + Numeric keys |
| Dimensions (W × D × H) |
458 x 464 x 388mm |
| Weight |
Approx. 24.8kg (without cartridge) |
| Power Consumption |
Maximum |
1470W |
| Average (During Operation) |
590W or less |
| Average (During Standby) |
34W or less |
| Average (During Sleep) |
Approx. 2.4W or less (USB)
Approx. 1.3W or less (wired) |
| Noise Level *3
|
During Operation: |
Sound Pressure Level: 50 / 51dB (mono / colour)
Sound Power Level: 6.5 / 6.6B (mono / colour) |
| During Standby: |
Sound Pressure Level: 36dB
Sound Power Level: 5B |
| Power Requirement |
AC 220 - 240V (±10%), 50 / 60 Hz (±2Hz） |
| Operating Environment |
Temperature：10 - 30°C
Humidity：20 - 80% RH（no condensation） |
| Toner Cartridge *4
|
Standard |
Cartridge 040 BK: 6,300 pages (bundled: 6,300 pages)
Cartridge 040 C / M / Y: 5,400 pages (bundled: 5,400 pages) |
| High Yield |
Cartridge 040H BK: 12,500 pages
Cartridge 040H C / M / Y: 10,000 pages |
| Waste Toner |
Waste Toner Box WT-B1: 54,000 pages |
| Duty Cycle *5
|
80,000 pages |
| Optional Accessories |
|
| SD Card |
SD CARD-C1 |
| Barcode ROM |
Barcode Print Kit-F1 |
| Paper Feeder |
Paper Feeder PF-D1 (550 sheets) |
